Show all photos
Specifications
Working height
3 m
Scaffolding length
1.88 m
Scaffolding width
841 mm
Scaffolding height
1.72 m
Platform width
750 mm
Platform length
1.8 m
Load capacity
1.5 kN/m2
Transport dimensions (plus packaging)
1900 x 1100 x 500 mm, 37 kg
Indoor use, central installation
possible & allowed
Outdoor use, central installation
possible & allowed
Ballasting of scaffolding, indoor, central installation
0 kg
Ballasting of scaffolding, outdoor, central installation
0 kg
Business division
MUNK Günzburger Steigtechnik
Platform height
990 mm
Information
- Mobile scaffolding made of sturdy round aluminium tubing with welded frame parts
- Folding frame made of rectangular tube side-rails with self-locking hinges
- Fits through doors when assembled (item no. 115301)
- Space-saving transport and storage
- Four Ø 125 mm swivel castors with locking mechanisms
- Slip-resistant platform for secure standing
- Delivered in assemblies. Once assembled, the scaffolding can be quickly set up and dismantled without tools
- Different platform widths available (0.75 / 1.35 m)
- Type-tested
- Load class/scaffolding group 2: 1.5 kN/m²
- Additional side boards for intermediate platforms are available as an option for country-specific requirements (e.g. Austria and France)
- Mobile scaffolding made of sturdy round aluminium tubing with welded frame parts
- Folding frame made of rectangular tube side-rails with self-locking hinges
- Fits through doors when assembled (item no. 115301)
- Space-saving transport and storage
- Four Ø 125 mm swivel castors with locking mechanisms
- Slip-resistant platform for secure standing
- Delivered in assemblies. Once assembled, the scaffolding can be quickly set up and dismantled without tools
- Different platform widths available (0.75 / 1.35 m)
- Type-tested
- Load class/scaffolding group 2: 1.5 kN/m²
- Additional side boards for intermediate platforms are available as an option for country-specific requirements (e.g. Austria and France)
Scope of supply
- 027945 - Folding frame unit with swivel castors: 1 x
- 027254 - Platform without flap: 1 x
- Instructions for assembly and use EN 1004-2 - de: 1 x
Best Brand of the Year 2025 – Plus X Award
- MUNK is the only company in the access equipment industry to receive this award.
- The jury's reasoning: MUNK stands for safety, innovation and responsibility in the field of access equipment like no other brand. With excellent product quality, a strong customer focus and sustainable practices, MUNK has been setting standards for years.
Safety. Made in Germany.
Comparison table
| Product name | Folding scaffolding for narrow passages Platform height 0.99 m | Folding scaffolding Platform height 0.99 m |
|---|---|---|
| Working height | 3 m | 3 m |
| Scaffolding length | 1.88 m | 1.88 m |
| Scaffolding width | 841 mm | 1.44 m |
| Scaffolding height | 1.72 m | 1.72 m |
| Platform width | 750 mm | 1.35 m |
| Platform length | 1.8 m | 1.8 m |
| Load capacity | 1.5 kN/m2 | 1.5 kN/m2 |
| Transport dimensions (plus packaging) | 1900 x 1100 x 500 mm, 37 kg | 1900 x 1400 x 500 mm, 54 kg |
| Indoor use, central installation | possible & allowed | possible & allowed |
| Outdoor use, central installation | possible & allowed | possible & allowed |
| Ballasting of scaffolding, indoor, central installation | 0 kg | 0 kg |
| Ballasting of scaffolding, outdoor, central installation | 0 kg | 0 kg |
| Business division | MUNK Günzburger Steigtechnik | MUNK Günzburger Steigtechnik |
| Platform height | 990 mm | 990 mm |
| Buy online | Buy online | Buy online |
Note on the BG BAU work safety subsidy
Expand your scaffolding with a safety railing (SG) and ensure reliable protection at work thanks to the system-integrated side protection! The retrofit reduces the risk of falling and enables the BG BAU work safety subsidy to be paid for up to 50% of the purchase costs (max. 100 euro per measure).
✔ Suitable for this product: Compatible SG safety railings offer effective side protection and are easy to retrofit.
All members of the BG BAU profit from this subsidy. This is intended to prevent accidents at work and improve ergonomics, especially on construction sites. All information from BG BAU can be found at: www.bgbau.de/service/angebote/arbeitsschutzpraemien
A brief overview of the subsidy and an overview of our eligible products can be found on our website at Knowledge.
Technical changes and price changes reserved. Dimensions and weights are approximate values. Liability for errors and mistakes excluded. Illustrations similar, some illustrations show special equipment. Preview images are representative of a product family and may therefore differ visually from the actual product you are looking for, e.g. in terms of number of steps or material.
