Show all photos
Specifications
Working height
4 m
Platform height max.
2 m
Cage length
770 mm
Cage width
640 mm
Base area length
1.18 m
Base area width
735 mm
Height
2 m
Inclination
0 °
Max. load capacity
135 kg
Transport dimensions
1180 x 735 x 1670 mm, 275 kg
Business division
MUNK Günzburger Steigtechnik
Order no.
127112
Information
- Manually operated vertical mast lift with intuitive one-handed operation
- All-round secured working area up to working heights of 4.00 m indoors
- low weight for easy handling
- Automatic braking device when lifting the workman basket
- Stepless and non-electric lifting mechanism with gas pressure spring
- Easy to enter and exit via swing door
- Robust design for extra durability
- Low operating costs, practically maintenance-free
- Anti-theft device with padlock
- These products are covered by the statutory warranty
- Corporate certification: ISO 9001
- Corporate certification: ISO 14001
- Corporate certification: EN 1090
- Corporate certification: EcoVadis
- RoHS
- REACH
- The MUNK Group complies with a Code of Conduct
- The Supply Chain Act does not apply due to our size
- The materials used are listed in the technical specification
- Resource-saving production: own photovoltaic systems
- Energy-efficient consumption during production: LED lighting
- Repairability, durability and quality: 15-year warranty on series products made in Germany
- Recyclability: Our products are mostly made of aluminium, steel or wood and can be fed directly into the recycling process.
- Socially acceptable working conditions in production: fair wages, gender equality
- Economical and recyclable packaging: no use of polystyrene, predominantly use of wood and cardboard, small amounts of plastic
- No health hazards for the users
Scope of supply
- Lift: 1 x
Best Brand of the Year 2025 – Plus X Award
- MUNK is the only company in the access equipment industry to receive this award.
- The jury's reasoning: MUNK stands for safety, innovation and responsibility in the field of access equipment like no other brand. With excellent product quality, a strong customer focus and sustainable practices, MUNK has been setting standards for years.
Certificates
Technical changes and price changes reserved. Dimensions and weights are approximate values. Liability for errors and mistakes excluded. Illustrations similar, some illustrations show special equipment. Preview images are representative of a product family and may therefore differ visually from the actual product you are looking for, e.g. in terms of number of steps or material.
