Show all photos
Specifications
Working height
3 m
Step design
Rungs
Number of steps/rungs
4 rungs
Platform included as step
Yes
Platform height
1.02 m
Platform length
655 mm
Platform width
480 mm
Step/Rung height
30 mm
Step depth
30 mm
Step/Rung distance
280 mm
Base spread
1.15 m
Inclination
70 °
Outer width
672 mm
Width incl. extension arm
1.64 m
Depth of side-rails
58 mm
Width of side-rails
25 mm
Castor diameter
150 mm
Max. load capacity
150 kg
Design type
Freestanding | Single-sided access | With castors
Transport dimensions (plus packaging)
2420 x 770 x 390 mm, 27 kg
Business division
MUNK Günzburger Steigtechnik
Order no.
052524
Information
- Platform ladder made of aluminium
- Stable rectangular tube side-rails
- Rectangular rungs grooved on both sides, 30 x 30 mm
- Spacious platform made of grooved aluminium chequered plate 480 x 655 mm
- 4-fold edged rung-to-side-rail connection
- With handrail on both sides, 3-sided, 1,000 mm high railing with knee and foot rails
- Infinitely variably adjustable outriggers on both sides
- Automatically closing safety door
- Generous sized tool tray
- Two Ø 150 mm castors and practical folding mechanism for quickly moving to a new location
- Available with and without flexible telescopic push-fit attachment
- Design compliant DIN EN 131-7 and the French standards NFP 93-352/353
- Maximum load: 150 kg
- Platform ladder made of aluminium
- Stable rectangular tube side-rails
- Rectangular rungs grooved on both sides, 30 x 30 mm
- Spacious platform made of grooved aluminium chequered plate 480 x 655 mm
- 4-fold edged rung-to-side-rail connection
- With handrail on both sides, 3-sided, 1,000 mm high railing with knee and foot rails
- Infinitely variably adjustable outriggers on both sides
- Automatically closing safety door
- Generous sized tool tray
- Two Ø 150 mm castors and practical folding mechanism for quickly moving to a new location
- Available with and without flexible telescopic push-fit attachment
- Design compliant DIN EN 131-7 and the French standards NFP 93-352/353
- Maximum load: 150 kg
Scope of supply
- Ladder: 1 x
- Handrail (enclosed separately): 2 x
- Castor (enclosed separately): 2 x
- Security door: 1 x
- Installation material: 1 x
- Assembly instructions: 1 x
Best Brand of the Year 2025 – Plus X Award
- MUNK is the only company in the access equipment industry to receive this award.
- The jury's reasoning: MUNK stands for safety, innovation and responsibility in the field of access equipment like no other brand. With excellent product quality, a strong customer focus and sustainable practices, MUNK has been setting standards for years.
Safety. Made in Germany.
Comparison table
| Product name | Platform ladder FlexxStep 4 rungs | Platform ladder FlexxStep 5 rungs | Platform ladder FlexxStep 6 rungs |
|---|---|---|---|
| Working height | 3 m | 3.3 m | 3.55 m |
| Step design | Rungs | Rungs | Rungs |
| Number of steps/rungs | 4 rungs | 5 rungs | 6 rungs |
| Platform included as step | Yes | Yes | Yes |
| Platform height | 1.02 m | 1.28 m | 1.55 m |
| Platform length | 655 mm | 655 mm | 655 mm |
| Platform width | 480 mm | 480 mm | 480 mm |
| Step/Rung height | 30 mm | 30 mm | 30 mm |
| Step depth | 30 mm | 30 mm | 30 mm |
| Step/Rung distance | 280 mm | 280 mm | 280 mm |
| Base spread | 1.15 m | 1.35 m | 1.52 m |
| Inclination | 70 ° | 70 ° | 70 ° |
| Outer width | 672 mm | 672 mm | 672 mm |
| Width incl. extension arm | 1.64 m | 1.98 m | 1.89 m |
| Depth of side-rails | 58 mm | 58 mm | 58 mm |
| Width of side-rails | 25 mm | 25 mm | 25 mm |
| Castor diameter | 150 mm | 150 mm | 150 mm |
| Max. load capacity | 150 kg | 150 kg | 150 kg |
| Design type | Freestanding | Single-sided access | With castors | Freestanding | Single-sided access | With castors | Freestanding | Single-sided access | With castors |
| Transport dimensions (plus packaging) | 2420 x 770 x 390 mm, 27 kg | 2735 x 760 x 390 mm, 29 kg | 3000 x 785 x 390 mm, 30.5 kg |
| Business division | MUNK Günzburger Steigtechnik | MUNK Günzburger Steigtechnik | MUNK Günzburger Steigtechnik |
| Order no. | 052524 | 052525 | 052526 |
| Buy online | Buy online | Buy online | Buy online |
Product video
Technical changes and price changes reserved. Dimensions and weights are approximate values. Liability for errors and mistakes excluded. Illustrations similar, some illustrations show special equipment. Preview images are representative of a product family and may therefore differ visually from the actual product you are looking for, e.g. in terms of number of steps or material.
