Specifications
Information
- Platform ladder made of aluminium
- Works directly above the toilet, perfect for narrow cubicles, limited space and for ceiling and wall work
- Full work surface without space issues, fits perfectly in sanitary cubicles and enables ceiling and wall work
- Stable rectangular tube side-rails
- Grooved steps with a depth of 80 mm
- Large, trapeze-shaped platform (400 / 340 x 425 mm)
- 4-fold edged step-to-side-rail connection
- Conical side-rail guide for safe stance
- Two handrails for safe ascent and descent (enclosed separately)
- 'safe-cap' ladder joint
- Practical storage tray (350 x 200 mm)
- Rigid connection through metal struts detachable on both sides
- Spreader lock with two high-strength polyester straps
- Two castors, Ø 125 mm, for easy movement from place to place
- Step spacing: 235 mm
- Ladder inclination: 70°
- Maximum load: 150 kg
The platform ladder for sanitary cubicles has been specially developed for use in confined spaces. Its sophisticated design allows the work platform to be positioned directly above a toilet without causing space problems. This makes it the ideal solution for maintenance, cleaning or installation work in narrow sanitary cubicles or changing rooms. The spacious, non-slip platform provides a secure footing and sufficient freedom of movement to carry out ceiling and wall work efficiently.
Thanks to the integrated transport rollers, the ladder can be easily moved, which is particularly advantageous when working in different locations in sanitary facilities. When folded, it can be stored in a space-saving manner and fits through any standard door. The side handrails provide a stable hold when ascending and descending and increase work safety – even in wet floor conditions.
Made of lightweight, robust aluminium, the platform ladder is ideal for daily use in demanding work environments. It is specifically aimed at professional users in facility management, building cleaning, the skilled trades and the sanitary and building services industry. Its combination of compact design, high functionality and practical features makes it an indispensable tool wherever space is limited but full performance is required.
- Corporate certification: ISO 9001
- Corporate certification: ISO 14001
- Corporate certification: EN 1090
- Corporate certification: EcoVadis
- RoHS
- REACH
- The MUNK Group complies with a Code of Conduct
- The Supply Chain Act does not apply due to our size
- The materials used are listed in the technical specification
- Resource-saving production: own photovoltaic systems
- Energy-efficient consumption during production: LED lighting
- Repairability, durability and quality: 15-year warranty on series products made in Germany
- Recyclability: Our products are mostly made of aluminium, steel or wood and can be fed directly into the recycling process.
- Socially acceptable working conditions in production: fair wages, gender equality
- Economical and recyclable packaging: no use of polystyrene, predominantly use of wood and cardboard, small amounts of plastic
- No health hazards for the users
- Ladder: 1 x
- Handrail (enclosed separately): 2 x
- Lifting castors: 2 x
Best Brand of the Year 2025 – Plus X Award
- MUNK is the only company in the access equipment industry to receive this award.
- The jury's reasoning: MUNK stands for safety, innovation and responsibility in the field of access equipment like no other brand. With excellent product quality, a strong customer focus and sustainable practices, MUNK has been setting standards for years.
Safety. Made in Germany.
Comparison table
| Product name | Platform manager for sanitation 3 steps with storage tray | Platform manager for sanitation 4 steps with storage tray | Platform manager for sanitation 5 steps with storage tray |
|---|---|---|---|
| Working height | 2.69 m | 2.9 m | 3.15 m |
| Step design | Steps | Steps | Steps |
| Number of steps/rungs | 3 steps | 4 steps | 5 steps |
| Platform included as step | Yes | Yes | Yes |
| Platform height | 687 mm | 900 mm | 1.13 m |
| Step depth | 80 mm | 80 mm | 80 mm |
| Step/Rung distance | 235 mm | 235 mm | 235 mm |
| Height | 1.44 m | 1.65 m | 1.88 m |
| Base spread | 848 mm | 1 m | 1.15 m |
| Inclination | 70 ° | 70 ° | 70 ° |
| Lower outer width | 574 mm | 610 mm | 640 mm |
| Depth of side-rails | 73 mm | 73 mm | 73 mm |
| Depth of side-rails, support | 58 mm | 58 mm | 58 mm |
| Width of side-rails | 25 mm | 25 mm | 25 mm |
| Max. load capacity | 150 kg | 150 kg | 150 kg |
| Design type | Freestanding | Single-sided access | Freestanding | Single-sided access | Freestanding | Single-sided access |
| Transport dimensions | 1437 x 574 x 164 mm, 8.9 kg | 1752 x 605 x 164 mm, 10 kg | 2002 x 635 x 163 mm, 11.5 kg |
| Business division | MUNK Günzburger Steigtechnik | MUNK Günzburger Steigtechnik | MUNK Günzburger Steigtechnik |
| Order no. | 052090 | 052091 | 052092 |
