Specifications
Material
Galvanised steel
Weight/piece
5 g
Groove size
6 mm
ISO thread
M6
Dimension A
17 mm
Dimension B
10 mm
Dimension C
7.9 mm
Business division
MUNK Profiltechnik
Order no.
930201
Information
- High-strength steel slot nuts
- For assembling profiles, construction parts and accessories in a range of positions
- Particularly suitable for exposure to dynamic stresses
- Slot nuts are swivelled into the side of the profile slot or inserted into the front
The connecting element for every profile size! MUNK Profiltechnik slot nuts made of galvanised steel enable force-fit connections of profiles, accessories and construction parts – with M5, M6 and M8 threads suitable for all T-slot sizes.
Universally applicable for all profile combinations
- For 6 mm slots: M5 and M6 threads (17×10 mm, 5 g)
- For 8 mm slots: M5, M6 and M8 threads (13.3×22.3 mm, 7 g)
- Galvanised steel: Corrosion protection for continuous use in industrial and outdoor applications
- High-strength design: Particularly suitable for dynamic loads
Flexible installation without machining
Sliding blocks are swivelled into the profile groove from the side or inserted from the front – ideal for initial installation and subsequent extensions. No drilling or machining of the profile is necessary.
Typical areas of application
- Machine frames: Force-fit fastening of panels and accessories
- Enclosures: Flexible installation of protective glazing and doors
- Workstations: Variable positioning of shelves and tool holders
- Automation technology: Secure mounting of sensors and actuators
- Conveyor technology: Dynamically stable connections in moving structures
Discover MUNK slot nuts – the universal basis for force-fit T-slot connections that fit perfectly today and can be flexibly repositioned tomorrow.
- High-strength steel slot nuts
- For assembling profiles, construction parts and accessories in a range of positions
- Particularly suitable for exposure to dynamic stresses
- Slot nuts are swivelled into the side of the profile slot or inserted into the front
Scope of supply
- Slot nut: 1 x
Comparison table
| Product name | M5 slot nut 6 mm slot | M6 slot nut 6 mm slot Slot nut-930201 | M5 slot nut 8 mm slot | M6 slot nut 8 mm slot | M8 slot nut 8 mm slot |
|---|---|---|---|---|---|
| Material | Galvanised steel | Galvanised steel | Galvanised steel | Galvanised steel | Galvanised steel |
| Weight/piece | 5 g | 5 g | 7 g | 7 g | 7 g |
| Groove size | 6 mm | 6 mm | 8 mm | 8 mm | 8 mm |
| ISO thread | M5 | M6 | M5 | M6 | M8 |
| Dimension A | 17 mm | 17 mm | 13.3 mm | 13.3 mm | 13.3 mm |
| Dimension B | 10 mm | 10 mm | 22.3 mm | 22.3 mm | 22.3 mm |
| Dimension C | 7.9 mm | 7.9 mm | 7.4 mm | 7.4 mm | 7.4 mm |
| Business division | MUNK Profiltechnik | MUNK Profiltechnik | MUNK Profiltechnik | MUNK Profiltechnik | MUNK Profiltechnik |
| Order no. | 930200 | 930201 | 930202 | 930203 | 930204 |
Technical changes and price changes reserved. Dimensions and weights are approximate values. Liability for errors and mistakes excluded. Illustrations similar, some illustrations show special equipment. Preview images are representative of a product family and may therefore differ visually from the actual product you are looking for, e.g. in terms of number of steps or material.
