Specifications
Length
2.8 m
Outer width
520 mm
Step width
470 mm
Step/Rung height
30 mm
Step depth
30 mm
Step/Rung distance
280 mm
Number of steps/rungs
10 rungs
Depth of side-rails
60 mm
Max. load capacity
150 kg
Material
Aluminium
Transport dimensions (plus packaging)
2795 x 525 x 60 mm, 5.5 kg
Business division
MUNK Günzburger Steigtechnik
Order no.
062265
Spare part for article no.
510120
Spare part for article no.
510105
Spare part for article no.
510110
Spare part for article no.
510125
Spare part for article no.
510100
Information
- Ladder width 520 mm
- Rung distance: 280 mm
- Side-rail dimensions: 60 x 25 mm
- Dimension of rungs: 30 x 30 mm
- Rung design: with anodised aluminium and bright aluminium grooved rungs, with galvanised steel and stainless steel perforated rungs
- Ladder width 520 mm
- Rung distance: 280 mm
- Side-rail dimensions: 60 x 25 mm
- Dimension of rungs: 30 x 30 mm
- Rung design: with anodised aluminium and bright aluminium grooved rungs, with galvanised steel and stainless steel perforated rungs
Scope of supply
- Ladder section: 1 x
Best Brand of the Year 2025 – Plus X Award
- MUNK is the only company in the access equipment industry to receive this award.
- The jury's reasoning: MUNK stands for safety, innovation and responsibility in the field of access equipment like no other brand. With excellent product quality, a strong customer focus and sustainable practices, MUNK has been setting standards for years.
Safety. Made in Germany.
Comparison table
| Product name | Ladder section bright aluminium 7 rungs | Ladder section bright aluminium 10 rungs | Ladder section bright aluminium 13 rungs Bright aluminium |
|---|---|---|---|
| Length | 1.96 m | 2.8 m | 3.64 m |
| Outer width | 520 mm | 520 mm | 520 mm |
| Step width | 470 mm | 470 mm | 470 mm |
| Step/Rung height | 30 mm | 30 mm | 30 mm |
| Step depth | 30 mm | 30 mm | 30 mm |
| Step/Rung distance | 280 mm | 280 mm | 280 mm |
| Number of steps/rungs | 7 rungs | 10 rungs | 13 rungs |
| Depth of side-rails | 60 mm | 60 mm | 60 mm |
| Max. load capacity | 150 kg | 150 kg | 150 kg |
| Material | Aluminium | Aluminium | Aluminium |
| Transport dimensions (plus packaging) | 1955 x 525 x 60 mm, 3.5 kg | 2795 x 525 x 60 mm, 5.5 kg | 3635 x 525 x 60 mm, 7 kg |
| Business division | MUNK Günzburger Steigtechnik | MUNK Günzburger Steigtechnik | MUNK Günzburger Steigtechnik |
| Order no. | 062264 | 062265 | 062266 |
| Buy online | Buy online | Buy online | Buy online |
Technical changes and price changes reserved. Dimensions and weights are approximate values. Liability for errors and mistakes excluded. Illustrations similar, some illustrations show special equipment. Preview images are representative of a product family and may therefore differ visually from the actual product you are looking for, e.g. in terms of number of steps or material.
