Specifications
Length
2.8 m
Outer width
520 mm
Step/Rung height
30 mm
Step depth
30 mm
Step/Rung distance
280 mm
Number of steps/rungs
10 rungs
Max. load capacity
150 kg
Material
Galvanised steel | S235JR/E235
Transport dimensions (plus packaging)
2795 x 520 x 60 mm, 16.5 kg
Business division
MUNK Günzburger Steigtechnik
Order no.
063265
Customs tariff number
73089098
Spare part for article no.
520120
Spare part for article no.
520105
Spare part for article no.
520100
Spare part for article no.
520110
Information
- Ladder width 520 mm
- Rung distance: 280 mm
- Side-rail dimensions: 60 x 25 mm
- Dimension of rungs: 30 x 30 mm
- Rung design: with anodised aluminium and bright aluminium grooved rungs, with galvanised steel and stainless steel perforated rungs
- Ladder width 520 mm
- Rung distance: 280 mm
- Side-rail dimensions: 60 x 25 mm
- Dimension of rungs: 30 x 30 mm
- Rung design: with anodised aluminium and bright aluminium grooved rungs, with galvanised steel and stainless steel perforated rungs
Scope of supply
- Ladder section: 1 x
Best Brand of the Year 2025 – Plus X Award
- MUNK is the only company in the access equipment industry to receive this award.
- The jury's reasoning: MUNK stands for safety, innovation and responsibility in the field of access equipment like no other brand. With excellent product quality, a strong customer focus and sustainable practices, MUNK has been setting standards for years.
Safety. Made in Germany.
Comparison table
| Product name | Ladder section galvanised steel 7 rungs | Ladder section galvanised steel 10 rungs | Ladder section galvanised steel 13 rungs |
|---|---|---|---|
| Length | 1.96 m | 2.8 m | 3.64 m |
| Outer width | 520 mm | 520 mm | 520 mm |
| Step/Rung height | 30 mm | 30 mm | 30 mm |
| Step depth | 30 mm | 30 mm | 30 mm |
| Step/Rung distance | 280 mm | 280 mm | 280 mm |
| Number of steps/rungs | 7 rungs | 10 rungs | 13 rungs |
| Max. load capacity | 150 kg | 150 kg | 150 kg |
| Material | Galvanised steel | S235JR/E235 | Galvanised steel | S235JR/E235 | Galvanised steel | S235JR/E235 |
| Transport dimensions (plus packaging) | 1955 x 520 x 60 mm, 11.5 kg | 2795 x 520 x 60 mm, 16.5 kg | 3635 x 520 x 60 mm, 21.5 kg |
| Business division | MUNK Günzburger Steigtechnik | MUNK Günzburger Steigtechnik | MUNK Günzburger Steigtechnik |
| Order no. | 063264 | 063265 | 063266 |
| Customs tariff number | 73089098 | 73089098 | 73089098 |
| Buy online | Buy online | Buy online | Buy online |
Technical changes and price changes reserved. Dimensions and weights are approximate values. Liability for errors and mistakes excluded. Illustrations similar, some illustrations show special equipment. Preview images are representative of a product family and may therefore differ visually from the actual product you are looking for, e.g. in terms of number of steps or material.
