Inspecting Portable Fire Service Ladders to DIN EN 1147

The inspection obligation arises from a tiered regulatory framework:

DIN EN 1147 is the primary European product standard for portable fire service ladders. It deliberately differs from the general ladder standard DIN EN 131, reflecting the extreme demands placed on equipment during rescue operations.

The standard covers all portable fire service ladders used in operations or training exercises:

• Scaling ladder (4-section): length approx. 8.40 m, rescue height approx. 7.20 m, 2 persons simultaneously
• Rope extension ladder (2-section): length approx. 8.50 m, rescue height approx. 7.20 m, 2 persons simultaneously
• Rope extension ladder (3-section): length approx. 14 m, rescue height approx. 12 m, 3 persons simultaneously, with support poles and rope hoist
• Hook ladder: length up to approx. 4.40 m, 1 person, with folding steel hook for window entry
• Multi-function ladder (3-section): length approx. 5.60 m, rescue height approx. 4.30 m, 2 persons, usable as a standing ladder, leaning ladder, or rescue platform
• Multi-function ladder (5-section): length approx. 9.20 m, rescue height approx. 7.70 m, 2 persons, usable as a standing ladder, leaning ladder, or rescue platform

• Folding ladder: length approx. 3.0 m, rescue height approx. 2.10 m, 1 person, highly compact transport dimensions

Under DIN EN 1147, all ladders must carry permanent, clearly visible markings showing: the publication date of the standard, manufacturer identification, ladder type, and year of manufacture. Ladders for which support poles are required must additionally bear a red band of at least 75 mm wide around the full circumference of the poles – fitted between 1.5 m and 2 m above the ladder feet.

After every use: visual inspection

After every operational deployment and before and after every training exercise, personnel carry out a visual inspection. This checks for obvious damage: deformations, cracks in stiles or rungs, and contamination that might conceal defects. This inspection is not subject to a documentation requirement, but it is safety-critical.

Annually: visual and functional inspection

At least every 12 months, a comprehensive visual and functional inspection must be carried out by a competent person. The inspection covers:

1. Check stiles for parallelism and deformation
2. Inspect rungs for deflection and damage
3. Examine connecting elements (hinges, joints, snap hooks, ropes on extension ladders)
4. Verify that all components are present and complete (ladder feet, end caps, markings)
5. Clean the ladder – oil, grease, or paint can mask defects

Every 24 months: load test

Important regulatory change since May 2021: the load test is no longer required annually but at least every 24 months – provided the annual visual and functional inspection found no defects and the ladder has been used solely for its intended purpose.

An immediate load test is required, however, when:

• the ladder has been subjected to exceptional stress (e.g. a fall or overloading)
• there are doubts about its safety
• the ladder has been used for a purpose other than its normal intended use
• repair work has been carried out that could affect structural integrity

For load testing, a ladder test stand is strongly recommended: it allows a precisely defined force to be applied, simplifies the mandatory hook load test for hook ladders and multi-function ladders, and makes the whole inspection process ergonomic and time-efficient.

The German Ordinance on Industrial Safety and Health (BetrSichV) stipulates that inspections may only be carried out by persons who have the necessary technical expertise through training, experience, and recent practice (TRBS 1203). In fire brigades, this responsibility is often held by the equipment officer, trained in accordance with the applicable state regulations (e.g. FwDV 2). Attending a manufacturer-specific training course is also advisable in order to gain hands-on knowledge of product-specific characteristics and current inspection requirements.

Critical note: the inspector must act with complete professional independence. The fire brigade's parent organisation may not influence the inspection outcome – neither through time pressure nor financial considerations. Anyone who has not conducted inspections for an extended period formally loses their competency status and must renew it through further training.

Every inspection must be fully documented – including the date, name and signature of the competent person, the inspection result, and any defects identified. Absent or incomplete documentation can result in loss of insurance cover in the event of an accident.

To support structured inspection documentation, our website provides inspection record sheets available to download.

Ladders that show defects or are no longer safe to use must be taken out of service immediately. They may only be returned to service after competent repair work has restored the original structural integrity. All repairs must be carried out to the required standard in accordance with BetrSichV § 10 (2) and signed off by a competent person.

• Lubricate joints: maintain jointed components in accordance with the manufacturer's instructions – this forms part of the annual servicing required under DGUV 305-002.
• Store dry and protected from UV: prevent corrosion and material embrittlement.
• Transport correctly: purpose-made ladder brackets prevent impact and crush damage.
• Check markings regularly: the data plate, CE marking, and manufacturer information must be legible and complete.

Anyone wishing to inspect fire service ladders as a competent person requires demonstrable technical expertise – and must keep it up to date. MUNK Group Campus offers two practice-oriented seminars for this purpose:

• One-day seminar: "Portable Fire Service Ladders and Rescue Platforms": fundamentals, standards, inspection obligations, and practical handling – all covered in a single day.
• Seminar: "Inspection and Maintenance of Portable Fire Service Ladders and Roll Containers": advanced inspection techniques, current changes to standards (DGUV 305-002, 2021 edition), and legally compliant documentation.

Both seminars are aimed at equipment officers, safety officers, and anyone with responsibility for the operational readiness of fire service equipment.

How often must a portable fire service ladder be inspected?

A visual inspection is carried out after every use. A visual and functional inspection by a competent person is required at least every 12 months. The load test is due at least every 24 months – provided no defects were identified during the visual inspection.

Who qualifies as a competent person?

Persons with a completed technical qualification, practical experience with the equipment, and recent active practice in accordance with TRBS 1203. In fire brigades, this is typically the equipment officer trained to FwDV 2 standards. The knowledge required to inspect portable fire service ladders, rescue platforms, and roll containers is covered in the seminars at MUNK Group Campus.

What happens if inspections are not documented?

Missing documentation can lead to liability claims and loss of insurance cover in the event of an accident.

When is an unscheduled inspection necessary?

Immediately after any exceptional stress (e.g. a fall or overloading), whenever there are doubts about the ladder's safety, or following repair work that may have affected structural integrity.

Does DIN EN 1147 also apply to roll containers?

No. Roll containers also fall under DGUV Principle 305-002, but are assessed against their own specific inspection criteria.

All inspection intervals and regulations cited in this article are based on DGUV Principle 305-002 (as of May 2021, updated December 2021) and DGUV Regulation 49. Standards and regulations are updated periodically – always consult the current version in force or seek advice from a qualified specialist.

Article last updated: May 2026
